Leuze 50146330; RK46C.DL3/2N-M12; Unpolarized retro-reflective photoelectric sensor

Application: Detection of polybags on conveyor belt, Detection of irregular objects on conveyor belt; Special version: Light-band; Operating range limit: 0.55 ... 1.5 m; Light source: LED, Red; Minimum object size: 3 mm, with optimum alignment and use. (see 'Further information').; Supply voltage: 10 ... 30 V, DC; Digital switching outputs: 2 Piece(s); Switching output 1: Transistor, NPN, Light switching; Switching output 2: Transistor, NPN, Dark switching; Switching frequency: 250 Hz; Connection: Connector, M12, Plastic, 4 -pin; Design, housing: Cubic; Dimensions: 20.5 mm x 76.3 mm x 44 mm; Housing material: Plastic; Operational controls: Teach button; Ambient temperature, operation: -40 ... 60 °C; Degree of protection: IP 69K, IP 67
