Wago - 2022-1807/999-953
$4.80
Wago - 2022-1807/999-953 is available to buy in increments of 1
Overview
4-pin ground carrier terminal block; for DIN-rail 35 x 15 and 35 x 7.5; green-yellow
- Connection data - Number of levels:1
- Mechanical Data - Design:horizontal type
- Connection data - Total number of potentials:1
- Material data - Color:green-yellow
- Mechanical Data - Mounting type:DIN-35 rail
- Physical data - Width:5.2 mm / 0.205 inches
- Material data - Note (material data):
Information on material specifications can be found here - Material data - Insulation material:Polyamide (PA66)
- Environmental requirements - Continuous operating temperature:-60 ... +105 °C
- Commercial data - GTIN:4055140000000
- Commercial data - ETIM 8.0:EC000901
- Commercial data - ETIM 7.0:EC000901
- Commercial data - Customs tariff number:85366990990
- sku_code:2022-1807/999-953
- Environmental Product Compliance - RoHS Compliance Status:Compliant,No Exemption
- approvals_General approvals:
- CCA - DEKRA Certification B.V. - C22.2 No. 158 - certificate 2437422
- KEMA/KEUR - DEKRA Certification B.V. - EN 60947 - certificate 71-116567
- UL - Underwriters Laboratories Inc. - UL 1059 - certificate E45172
- Electrical data - Ratings per IEC/EN - Ratings per:IEC/EN 60947-7-2
- Material data - Flammability class per UL94:V0
- Material data - Material group:I
- Notes - Safety information:A separator plate (item no. 209-191) or a 10 mm end stop (item no. 249-117) must be placed at the end of a WAGO X-COM(R)S-SYSTEM terminal strip.
- approvals_Approvals for hazardous areas:
- ATEX - Physikalisch Technische Bundesanstalt - EN IEC 60079-0 - certificate PTB 13 ATEX 1004 U (II3 G Ex ec II C Gc)
- CCC - CNEX - GB/T 3836.3 - certificate 2020312313000255 (Ex ec IIC Gc)
- IECEx - Physikalisch Technische Bundesanstalt - IEC 60079-0 - certificate IECEx PTB 13.0004U (Ex ec IIC Gc)
- Commercial data - Country of origin:CN
- Mechanical Data - Marking level:Center/side marking
- ACCESSORIES_Markingaccessories:
- 2002-161
- 2009-110
- 2009-115
- 2009-145
- 2009-191
- 2009-192
- 2009-193
- 2009-198
- 248-501
- 793-5501
- ACCESSORIES_Tools:210-720
- ACCESSORIES_Jumper:
- 2002-400
- 2002-402
- 2002-402/000-005
- 2002-402/000-006
- 2002-403
- 2002-403/000-005
- 2002-403/000-006
- 2002-404
- 2002-404/000-005
- 2002-404/000-006
- 2002-405
- 2002-405/000-005
- 2002-405/000-006
- 2002-405/011-000
- 2002-406
- 2002-406/000-005
- 2002-406/000-006
- 2002-406/020-000
- 2002-407
- 2002-407/000-005
- mandatory_ACCESSORIES_Endplate:
- 2022-1891
- 2022-1892
- ACCESSORIES_Carrierrail:
- 210-112
- 210-113
- 210-114
- 210-115
- 210-118
- 210-196
- 210-197
- 210-198
- ACCESSORIES_Coding:2022-100
- ACCESSORIES_Screwlessendstop:249-117
- ACCESSORIES_Push_Intypewirejumper:
- 2009-412
- 2009-414
- 2009-414/000-005
- 2009-414/000-006
- 2009-416
- manufacturer_description:4-pin ground carrier terminal block; for DIN-rail 35 x 15 and 35 x 7.5; green-yellow
- picture_filename_1:1024-1406175-DE.jpg
- picture_zoom_filename_1:2000-1406175-DE.jpg
- Material data - Weight:14.8g
- Physical data - Height:106 mm / 4.173 inches
- Physical data - Depth from upper-edge of DIN-rail:32.5 mm / 1.28 inches
- Primary brand: Wago
- Functions: Carrier ground/earthing terminal block
- Design: 1-deck/level
- Poles: 1 grounding / protective-earth (1PE)
- Color: Green-Yellow
- Connection capacity: 4-wires (2 plug-in pins + 2 plug-in pins) (2+2)
- Connection type: Plug-in pin connections
- Mounting mode: DIN-35 rail (35 x 15 / 35 x 7.5)
- Net Width (mm): 5.2mm
- GTIN code: 4055140000000
- ETIM code: EC000901
- Customs Tariff Number: 85366990990
- Order code / Manufacturer SKU: 2022-1807/999-953
- Manufacturer product status: Commercialized
- Equivalent to: 20221800000000
- EAN code: 4055140000000
- Compliant with standard(s):
- General approvals
- - CCA - DEKRA Certification B.V. - C22.2 No. 158 - certificate 2437422
- - KEMA/KEUR - DEKRA Certification B.V. - EN 60947 - certificate 71-116567
- - UL - Underwriters Laboratories Inc. - UL 1059 - certificate E45172
- Approvals for hazardous areas
- - ATEX - Physikalisch Technische Bundesanstalt - EN IEC 60079-0 - certificate PTB 13 ATEX 1004 U (II3 G Ex ec II C Gc)
- - CCC - CNEX - GB/T 3836.3 - certificate 2020312313000255 (Ex ec IIC Gc)
- - IECEx - Physikalisch Technische Bundesanstalt - IEC 60079-0 - certificate IECEx PTB 13.0004U (Ex ec IIC Gc)
- RoHS compliant
- V-0 flammability rating
- Location of origin: China
- Cross-sells with:
- 2022-1891
- 2022-1892
- 2002-161
- 2002-400
- 2002-402
- 2002-402/000-005
- 2002-402/000-006
- 2002-403
- 2002-403/000-005
- 2002-403/000-006
- 2002-404
- 2002-404/000-005
- 2002-404/000-006
- 2002-405
- 2002-405/000-005
- 2002-405/000-006
- 2002-405/011-000
- 2002-406
- 2002-406/000-005
- 2002-406/000-006
- 2002-406/020-000
- 2002-407
- 2002-407/000-005
- 2009-110
- 2009-115
- 2009-145
- 2009-191
- 2009-192
- 2009-193
- 2009-198
- 2009-412
- 2009-414
- 2009-414/000-005
- 2009-414/000-006
- 2009-416
- 2022-100
- 210-112
- 210-113
- 210-114
- 210-115
- 210-196
- 210-197
- 210-198
- 210-720
- 248-501
- 249-117
- 793-5501
- Level 1 category: Electrical components
- Level 2 category: Terminal blocks
- Product title: Carrier ground/earthing terminal block - 1-deck/level - Wago (X-COM S series)
| Main function | Terminal |
|---|---|
| Product series / family name | 2022 series |
| Sub-range name | X-COM S series |
| Poles | PE |
| Connection capacity | 4-wires (2+2) |
| Connection type (electrical) | Plug-in |
| Mounting mode | DIN rail, DIN rail (NS 35/7.5) |
| Dimensions (mm) | W5...5.2mm |
| Type - Conductor insertion and removal | with tool |
| Type - Decks | 1 |
| Type - Terminal | grounding / earthing |
| Type - Option | Standard (No options) |
